Where is the coolant temperature sensor located on this engine?

Discussion in 'Heavy Duty Diesel Truck Mechanics Forum' started by Verdel, Nov 19, 2021.

  1. Nov 19, 2021 #1
    Verdel

    Verdel Medium Load Member

    596
    135
    Oct 26, 2013
    0
    Hello, recently purchased this 2015 Freightliner straight truck with Cummins engine ISB 6.7 - 280 HP.
    I am just wondering where exactly is the coolant temperature sensor located ? Here is the picture of the engine tag. Thank you.

    Verdel, Nov 19, 2021
    Verdel, Nov 19, 2021
    #1
  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Nov 19, 2021 #2
    WrenchWrenchWrench

    WrenchWrenchWrench Light Load Member

    131
    118
    Jan 3, 2016
    0
    Front of the engine, passenger side in the thermostat housing. Where the upper radiator hose leaves the engine, it will be the two wire sensor right there.

    WrenchWrenchWrench, Nov 19, 2021
    WrenchWrenchWrench, Nov 19, 2021
    #2
    biopure22, MOBee and Oxbow Thank this.
