Oil leak paccar mx 13

Discussion in 'Heavy Duty Diesel Truck Mechanics Forum' started by insanityeight, Jun 21, 2019.

  1. insanityeight

    insanityeight Light Load Member

    287
    111
    Jul 26, 2013
    birmingham al
    0
    My blowby tube actual has a drip to it and the crankcase ventilation module that it connects to is covered in oil. The big lines that come down from front valve cover and attach to it appear to be leaking somewhere as there is greasy dust buildup all over it in spots. Dont think its the ventilation module. No codes and if i lay oil cap upside down on oil fill hole and rev motor it doesnt blow it off but seems to be consuming a bit of oil lately and making a mess underneath truck. Any ideas?? Thanks in advance upload_2019-6-21_17-7-19.png upload_2019-6-21_17-7-19.jpeg
    Thanks in advance

  2. Truckers Report Jobs

    Trucking Jobs in 30 seconds

    Every month 400 people find a job with the help of TruckersReport.

  3. Goodysnap

    Goodysnap Road Train Member

    3,694
    8,948
    Jul 12, 2017
    0
    What you are seeing is not uncommon IMO. Older engines that work hard it is typical to see buildup and seepage in these areas. I would steam it off and monitor for continued leaks. Might consider replacing the tube from the valve cover to the module first. The tube is made for ease of removal and does not have the highest level of technology when it comes to sealing. They are not the thickest or the most durable either.

    insanityeight Thanks this.
  4. insanityeight

    insanityeight Light Load Member

    287
    111
    Jul 26, 2013
    birmingham al
    0
    Should wet oil be coming down through that tube and leaking out making a mess?thinking about removing the ventilation module and seeing if the filter is replaceable and maybe adding some heavy oil to thicken it up

  5. Goodysnap

    Goodysnap Road Train Member

    3,694
    8,948
    Jul 12, 2017
    0
    The EPA 10 engines that had a crankcase filter have a oil pressure driven centrifugal spinner to separate the oil from vapor and return the oil to the crankcase. Either you have a leak or you actually have excessive blowby that is overwhelming the spinner. There is no filter element. Thicker oil will not help longterm.

    BoxCarKidd and insanityeight Thank this.
  6. insanityeight

    insanityeight Light Load Member

    287
    111
    Jul 26, 2013
    birmingham al
    0
    Mines epa 10 and dealer said its an electric spinner like u said so maybe the leaking line coming down is my problem. Thanks for the input. I appreciate it very much.

    Goodysnap Thanks this.
  7. Goodysnap

    Goodysnap Road Train Member

    3,694
    8,948
    Jul 12, 2017
    0
    EPA 13 and newer use electric ccv spinner. EPA 10 does not.

  8. insanityeight

    insanityeight Light Load Member

    287
    111
    Jul 26, 2013
    birmingham al
    0
    I gave him my vin so he mus be a dummy,thanks man

    Goodysnap Thanks this.
  9. insanityeight

    insanityeight Light Load Member

    287
    111
    Jul 26, 2013
    birmingham al
    0
    Oh have you any experience with a product called AT-205 reseal to recondition engine seals and if so do u recommend or no?

    Edjahman Thanks this.
  10. Goodysnap

    Goodysnap Road Train Member

    3,694
    8,948
    Jul 12, 2017
    0
    Never heard of it. I have never had pour in potions that work long term, therefore I do not recommend them.

    insanityeight Thanks this.
  11. Goodysnap

    Goodysnap Road Train Member

    3,694
    8,948
    Jul 12, 2017
    0
    See diagram of EPA 10 oil separator.


    Attached Files:

    Trooper13 and insanityeight Thank this.
