Cascadia Dash Cluster Not Working

Have a 2013 Cascadia Isx/15 . Dash worked fine last night went to pull out of shop this AM all gauges not working no display of milage . I have extra gauges swap them out nothing.None of the gauges will sweep upon key on. Lights work in cluster and low air warning. I am thinking there must be a module in the cluster that controls the gauges. I also think the driver may have spilled something in the cluster. Thanks



ICU4



Thanks Rocket Man I appreciate the info . I ordered a light bar for Monday . Hopefully thats it lot of money . I have always had problems with a couple of these trucks in the fleet with the Fuel/DEF and oil ga. intermittently fluctuating or the red lights flashing in the ga. Tap on them alot of times they will be OK for awhile. I have been trying to get access to Freightliner's service link but have not been accepted. THANKS AGAIN FOR THE GOOD INFO



Rocket Man can you help me some more. Replaced the ICU light bar most of the dash worked . Did find bad connection at air ga. replaced ga. and the two daisy chain. The problem now is I can't keep the mileage to stay on the display. It will not automatically like before . The driver says he needs to keep pulling it up from the programing of the dash. When it is displayed when you shut truck off and restart it is gone. What is displayed is the amount of miles i think from when I replaced the light bar plus the voltage Any ideas or what else needs to be programmed . I asked Freightliner if there was any programming needed they told me no.



The mileage will not stay displayed
